- Powder coat epoxy cast iron housing
- Zone hardened inner ring with 120° spacing setscrew lock with diamond faceted setscrews
- Single lip contact seal and flinger
VFBS-223
Browning Mounted Cast Iron Three Bolt Flange Bracket Ball Bearing – 52100 Bearing Steel, Black Oxided Inner – Setscrew Lock – VFBS-223
Out of stock
| Bore Shape: | Straight | Housing Base: | Solid |
|---|---|---|---|
| Rolling Element: | Ball Bearing | Seal Type: | Single Lip Contact Seal with Flinger |
| Insert Material: | 52100 Bearing Steel, Black Oxided Inner | Measure Units: | Inch |
| Pilot Configuration: | No Pilot | Radial Dynamic Load Capacity (lb): | 5, 782 lb |
| Internal Clearance: | Standard | Misalignment: | ±1.5° Misalignment - Static Only |
| Housing Construction: | One Piece | Bearing Insert Coating: | Black Oxide Coated Inner Ring |
| Outer Ring Land Profile: | Standard | Replaceable Insert: | Yes |
| Misalignment Type: | Static Only | End Cap: | No |
| Housing Color: | Gray | Retainer Material: | Molded fiber glass reinforced nylon |
| Radial Static Load Capacity (lb): | 3, 493 lb | Duty/Series: | Standard Duty |
| Maximum Speed (RPM): | 4000 rpm | Housing Type: | Flange, Bracket, Three Bolt |
| Housing Material: | Cast Iron | Locking Type: | Setscrew |
| Retainer Type: | Ball Riding Retainer | Housing Style: | Flange Block |
| Lubrication Type: | Lithium Complex NLGI 2 Grease | Fixed vs. Expansion: | Fixed |
| Ability to Relubricate: | Yes | Maximum Operating Temperature (F): | 200 °F |
| Insert Number: | VS-223 | UPC: | 662460495873 |
| Weight: | 3.08 LB | Packaged Length: | 7.1 Inches |
| Packaged Width: | 4.5 Inches | Packaged Height: | 2.2 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | Mexico |
