- Wide race and rollers and steel cage for high dynamic load ratings
- Race-mounted felt seal with flinger and misalignment sealing
- Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
- Powder coat epoxy cast iron housing
USFC5000-311
Sealmaster Mounted Cast Iron Piloted Flange Spherical Roller – 52100 Bearing Steel, Black Oxided – Collar Mount Lock – USFC5000-311
$9,423.05
Out of stock
Out of stock
| Insert Material: | 52100 Bearing Steel, Black Oxided | Seal Type: | Felt Labyrinth Seal |
|---|---|---|---|
| Expansion: | Non-Expansion Bearing (Fixed) | Measure Units: | Inch |
| Rolling Element: | Spherical Roller | Housing Type: | Flange, Cartridge |
| Housing Material: | Cast Iron | Bore Shape: | Straight |
| Insert No.: | USI5000-311 | Pilot Configuration: | With Pilot |
| Relubricatable: | Yes | Misalignment: | ±2.0° Misalignment - Dynamic |
| Radial Dynamic Load Capacity (lb): | 96, 050 | Locking Type: | Single Set Collar |
| Duty Series: | Standard | Speed (Max): | 2250 |
| Lubrication: | Lithium Complex NLGI 2 Grease | Maximum Operating Temperature: | 220 °F |
| Housing Construction: | Solid | Internal Clearance: | Standard |
| Retainer Material: | Steel | End Cap: | No |
| Outer Ring Land Profile: | Standard | Platform: | USRB |
| Misalignment Type: | Dynamic | Replaceable Insert: | No |
| Bearing Insert Coating: | Black Oxide Coated | Housing Color: | Gray |
| Bolt Hole Type: | Round Hole | Series: | USFC5000 |
| Lubrication Method: | Lubrication Fitting | Radial Static Load Capacity (lb): | 136, 151 |
| Grease Fitting Thread Size: | 1/4-28 | UPC: | 662461362419 |
| Weight: | 42.34 LB | Packaged Length: | 11.19 Inches |
| Packaged Width: | 11 Inches | Packaged Height: | 4.88 Inches |
| HTC: | 8483.20.4080 | Country of Origin: | United States of America |
