TUE920X2

Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
Single lip contact face-riding seals rotate with the shaft
Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
Powder coat epoxy 2-bolt cast iron housing

Insert Material:	52100 Bearing Steel	Seal Type:	Single Lip Contact Seal
Housing Type:	Take Up, Wide Slot	Speed (Max):	2000
Measure Units:	Inch	Rolling Element:	Tapered Roller
Bore Shape:	Straight	Expansion:	No
Housing Material:	Cast Iron	Locking Type:	Double Collar Mount
Housing Construction:	One Piece	Radial Dynamic Load Capacity (lb):	8, 070 lb
Internal Clearance:	Standard	Frame Type:	Center Pull Wide Slot
Misalignment:	None	Misalignment Type:	None
Housing Color:	Gray	Retainer Material:	Steel
End Cap:	No	Bearing Insert Coating:	Uncoated
Replaceable Insert:	No	Outer Ring Land Profile:	Standard
Platform:	Type E	Series:	TUE920
Unit Type:	Side Mount	Grease Fitting Thread Size:	1/8 NPT
Component Description:	Take Up Bearing Only	Lubrication Type:	Lithium, EP, NLGI#2
Duty/Series:	Standard	Ability to Relubricate:	Yes
Housing Style:	Take-Up Block	Maximum Operating Temperature (F):	200 °F
Inner Race Heat Treat Method:	Case Carburized Inner Ring	UPC:	662289000000
Weight:	10.52 LB	Packaged Length:	6.38 Inches
Packaged Width:	6.31 Inches	Packaged Height:	3.88 Inches
HTC:	8483.20.4080	Country of Origin:	United States of America
