- Large Selection – MVP companion sheaves are offered in A/B, C, 5V & 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
- Statically Balanced – All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
- VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
- The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
- When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
- When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.
4MVC240R
Browning 4 Groove Cast Iron Bushed Bore Multiple Variable Pitch Sheave – 4MVC240R
Out of stock
| Number of Grooves: | 4 | Material: | Cast Iron |
|---|---|---|---|
| Product Type: | MVP Sheaves | Type of Bore: | Bushed |
| Bore (Max) (in): | 3.625 in | Outside Diameter (in): | 24.4 in |
| Bore (Min) (in): | 1.375 in | Pitch Diameter Range (C): | 24.4 |
| Outside Length (in): | 6.265625 in | Length Through Bore (in): | 4.875 in |
| Pulley Construction: | Arm | Number of Hubs: | 1 |
| Face Width (in): | 6.21875 in | Bushing Used: | R2 |
| Datum "C" Belts (in): | 24 in | Belt Section: | C |
| UPC: | 662289313150 | Weight: | 130.00 LB |
| Packaged Length: | 24.40 Inches | Packaged Width: | 24.40 Inches |
| Packaged Height: | 6.22 Inches | HTC: | 8483.50.9040 |
| Country of Origin: | Mexico |
