- High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
- High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
- High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
- Solid construction with machined base was designed for minimal gaps and no fillers
- Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
- Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
- Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
- USDA H1 complaint food grade grease
CRFS-PN31
Sealmaster Mounted Stainless Steel Four Bolt Flange Ball Bearing – 52100 Bearing Steel, Phosphorus Nickel Coated – Setscrew Lock – Corrosion Resistant – CRFS-PN31
$569.31
Out of stock
Out of stock
| Measure Units: | Inch | Housing Type: | Flange, Four Bolt |
|---|---|---|---|
| Rolling Element: | Ball Bearing | Expansion: | No |
| Insert No.: | PN-31 | Duty Series: | Standard Duty |
| Inner-Race Heat-Treat Method: | Zone-Hardened | Retainer Type: | Land Riding Retainer |
| Insert Material: | 52100 Bearing Steel, Phosphorus Nickel Coated | Maximum Operating Temperature: | 220 °F |
| Housing Base: | Solid | Housing Material: | Stainless Steel |
| Seal Type: | Multi-Lip Contact Seal | Bore Shape: | Straight |
| Radial Dynamic Load Capacity (lb): | 7, 889 | Pilot Configuration: | No Pilot |
| Relubricatable: | Yes | Speed (Max): | 1500 |
| Locking Type: | Setscrew | Internal Clearance: | Standard |
| Housing Construction: | One Piece | Lubrication: | Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease |
| Misalignment: | ±2.0° Misalignment - Static Only | Backside Shield/Seal: | Optional backside shield available order separate |
| Options: | Corrosion Resistant | Housing Color: | Silver |
| Outer Ring Land Profile: | Standard | Bearing Insert Coating: | Phosphorus Nickel Coated |
| Platform: | PN Gold | End Cap: | Yes |
| Misalignment Type: | Static Only | Replaceable Insert: | Yes |
| Certifications: | IP69K | Radial Static Load Capacity (lb): | 5, 216 |
| Cage Material: | PPS | UPC: | 662461337493 |
| Weight: | 6.70 LB | Packaged Length: | 6.75 Inches |
| Packaged Width: | 6.5 Inches | Packaged Height: | 2.44 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | United States of America |
