- Close Grain Cast iron – Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
6C500M
Browning 6 Groove Cast Iron Bushed Bore Multiple Sheave – 6C500M
Out of stock
| Number of Grooves: | 6 | Outside Diameter (in): | 50.4 in |
|---|---|---|---|
| Datum Diameter (C): | 50 | Bushing Used: | M |
| Material: | Cast Iron | Model Name: | 6C_LG_Sheavemaster |
| Pulley Material: | Cast Iron | Pitch Diameter (C): | 50.4 |
| Product Type: | Multiple Sheaves | Bore (Min) (in): | 2 in |
| Belt Section: | C | Bore Type: | QD Bushed |
| Bushing Bore Range: | 2.000 - 5.500 | UPC: | 662289370177 |
| Weight: | 320.00 LB | Packaged Length: | 50.40 Inches |
| Packaged Width: | 50.40 Inches | Packaged Height: | 6.25 Inches |
| HTC: | 8483.50.9040 | Country of Origin: | United States of America |
