- Browning offers one of the largest selection of application shaft ready sprockets in the industry
- Easy Installation and removal
- Split Taper Bushing are available in popular Inch, Metric and Spline bore
- Hardened Teeth at No Extra Cost – Drive Sizes up to 30 teeth on 35 through 160 Chain
D60R54
Browning Steel Bushed Bore Roller Chain Sprocket – D60R54
Out of stock
| Chain Used: | No. 60, 3/4 in. Pitch ANSI Chain | Bushing Used: | Split Taper |
|---|---|---|---|
| Bore (Max) (in): | 3.75 in | Bore (Min) (in): | 1.125 in |
| Material: | Steel | Product Type: | Bushed Roller Chain Sprocket |
| Number of teeth: | 54 | Pitch Diameter (in): | 12.899 in |
| Chain Pitch (in): | 0.75 in | Outside Diameter (in): | 13.327 in |
| Bore Type: | Bushed Bore | Overall Length (in): | 3.141375 in |
| Number of Strands/Width: | 2 | Hub Diameter (in): | 5.375 in |
| Minimum Bore (in): | 1.125 | Maximum Bore (in): | 3.75 |
| Width Across Tooth Sets: | 1.341 | Number of Hubs: | 1 |
| Pitch Type: | Single | UPC: | 662289109555 |
| Weight: | 44.04 LB | Packaged Length: | 14.00 Inches |
| Packaged Width: | 2.50 Inches | Packaged Height: | 14.00 Inches |
| HTC: | 8483.90.1050 | Country of Origin: | China |
