- Large Selection – MVP companion sheaves are offered in A/B, C, 5V & 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
- Statically Balanced – All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
- VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
- The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
- When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
- When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.
5MV5V97R
Browning 5 Groove Cast Iron Bushed Bore Multiple Variable Pitch Sheave – 5MV5V97R
$3,840.37
Out of stock
Out of stock
| Outside Length (in): | 5.90625 in | Product Type: | MVP Sheaves |
|---|---|---|---|
| Material: | Cast Iron | Bore (Max) (in): | 3.625 in |
| Pitch Diameter Range (5V): | 9.65 | Outside Diameter (in): | 9.75 in |
| Bore (Min) (in): | 1.375 in | Number of Grooves: | 5 |
| Type of Bore: | Bushed | Number of Hubs: | 1 |
| Length Through Bore (in): | 4.875 in | Pulley Construction: | Web |
| Face Width (in): | 5.5 in | Bushing Used: | R2 |
| Belt Section: | 5V | UPC: | 662289313228 |
| Weight: | 64.84 LB | Packaged Length: | 9.75 Inches |
| Packaged Width: | 9.75 Inches | Packaged Height: | 6.25 Inches |
| HTC: | 8483.50.9040 | Country of Origin: | Mexico |
