- Rugged Cast-Iron Housing: Provides maximum strength and dependability.
- High lead angle worm is case hardened, ground and polished.
- Large, Single Row Ball Bearings On Input Shaft: Absorb radial and thrust loads at higher input speeds. Tapered roller bearings are used on output shaft.
- Forged Bronze Worm Gears: Provide optimum balance of Strength and Wear.
175Q140R5
Morse Raider Plus Worm Gear Reducer Cast Iron Single-Reduction Worm Reducer – 175Q140R5
$1,100.86
Out of stock
Out of stock
| Reducer Style: | Standard | Input Speed: | 1750 |
|---|---|---|---|
| Ratio: | 5:1 | Shaft Seal Material: | Nitrile |
| Thrust Rating - output shaft: | 868 | Input Bore (C Face): | 0.875 |
| Input Keyway (C Face): | 3/16 X 3/32 | Efficiency: | 80 |
| Motor Frame Size: | 140TC | Mounting Style: | No Base |
| Center Distance (in): | 1.75 | Frame Size: | 140TC |
| Reducer: | Worm - Right Angle | Input RPM: | 1, 750 |
| Service Factor: | 1 | Assembly: | Q-R |
| Input Diameter (in): | 0.875 in | Output Diameter (in): | 0.875 in |
| Output Key: | 3/16 X 1.38 | Series Code: | Raider |
| Product Type: | Worm Speed Reducer | Gear Type: | Worm |
| Input HP @ 1750 RPM: | 2.45 | No. of Gear Reductions: | Single |
| Ratio Range: | 5:01 | Output Shaft Assembly Code: | R |
| Output RPM: | 350 | Model Code: | 175Q |
| Input Style: | C-Face Quill | Output Shaft Direction: | Right |
| Housing Material: | Cast Iron | Output Torque Rating (in-lb): | 436 in-lbs @1750 input RPM in/lbs |
| Overhung Load Rating (Output Shaft(lb)): | 663 lb | Output Shaft: | Solid Shaft |
| UPC: | 6, 62288E+11 | Weight: | 24.00 LB |
