- Browning Minimum Bore Spur Gear
- Browning Gears are rated in accordance with AGMA standards
- When you think “Special” Gears – Think Browning
YSS1640
Browning Steel Minimum Plain Bore Spur Gear – 20 PA 16 DP – YSS1640
$168.58
Out of stock
Out of stock
| Pitch Diameter (in): | 2.5 in | Outside Diameter (in): | 2.62 in |
|---|---|---|---|
| Hub Projection (in): | 0.625 in | Material: | Steel |
| Number of Teeth/Threads: | 40 | Hub Diameter (in): | 2.25 in |
| Diametral Pitch: | 16 | Face Width (in): | 0.75 in |
| Pressure Angle: | 20 | Bore (Min) (in): | 0.625 in |
| Bore Type: | Minimum Plain Bore | Bore (Max) (in): | 1.375 in |
| Length Through Bore (in): | 1.375 in | Product Type: | Spur Gear |
| Bore Size (in): | 0.625 in | Hub Type: | Type B |
| Overall Length (in): | 1.375 in | Standard Met: | AGMA |
| UPC: | 662289216055 | Weight: | 1.65 LB |
| Packaged Length: | 3.10 Inches | Packaged Width: | 3.20 Inches |
| Packaged Height: | 1.40 Inches | HTC: | 8483.40.9000 |
| Country of Origin: | Mexico |
