- Powder coat epoxy malleable iron housing
- Zone hardened inner ring with 120° spacing setscrew lock with diamond faceted setscrews
- Single lip contact seal
VF3S-122M
Browning Mounted Ductile Iron Three Bolt Flange Ball Bearing – 52100 Bearing Steel – Setscrew Lock – VF3S-122M
Out of stock
| Seal Type: | Single Lip Contact Seal | Insert Material: | 52100 Bearing Steel |
|---|---|---|---|
| Bore Shape: | Straight | Measure Units: | Inch |
| Rolling Element: | Ball Bearing | Housing Base: | Solid |
| Pilot Configuration: | No Pilot | Internal Clearance: | Standard |
| Misalignment: | ±1.5° Misalignment - Static Only | Housing Construction: | One Piece |
| Radial Dynamic Load Capacity (lb): | 5, 782 lb | Bearing Insert Coating: | Uncoated |
| Replaceable Insert: | Yes | Housing Color: | Gray |
| Outer Ring Land Profile: | Standard | Retainer Material: | Molded fiber glass reinforced nylon |
| Misalignment Type: | Static Only | End Cap: | No |
| Bolt Type: | Carriage Bolt | Radial Static Load Capacity (lb): | 3, 493 lb |
| Housing Material: | Ductile Iron | Retainer Type: | Ball Riding Retainer |
| Duty/Series: | Light Duty | Housing Type: | Flange, Three Bolt |
| Lubrication Type: | Lithium Complex NLGI 2 Grease | Housing Style: | Flange Block |
| Maximum Speed (RPM): | 2500 rpm | Locking Type: | Setscrew |
| Fixed vs. Expansion: | Fixed | Insert Number: | VS-122 |
| Maximum Operating Temperature (F): | 200 °F | Ability to Relubricate: | Yes |
| Inner Race Heat Treat Method: | Zone-Hardened | Bolt Hole Shape: | Square Hole |
| UPC: | 662289543243 | Weight: | 1.77 LB |
| Packaged Length: | 5 Inches | Packaged Width: | 2 Inches |
| Packaged Height: | 5 Inches | HTC: | 8483.20.4040 |
| Country of Origin: | Mexico |
