- Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
- Race-mounted contact flinger seal
- Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
- Powder coat epoxy 2-bolt split cast steel housing
SPB 308-C2
Sealmaster Mounted Cast Steel Two Bolt Pillow Block Tapered Roller – 52100 Bearing Steel – Double Collar Mount Lock – SPB 308-C2
$3,506.88
Out of stock
Out of stock
| Maximum Operating Temperature: | 220 °F | Expansion: | No |
|---|---|---|---|
| Inner-Race Heat-Treat Method: | Case Carburized Inner Ring | Seal Type: | Single Lip Contact Seal |
| Rolling Element: | Tapered Roller | Insert Material: | 52100 Bearing Steel |
| Housing Base: | Solid | Housing Type: | Pillow Block, Two Bolt |
| Measure Units: | Inch | Housing Material: | Cast Steel |
| Housing Construction: | Split Two Piece | Lubrication: | Lithium; EP; NLGI#2 |
| Internal Clearance: | Standard | Insert No.: | RCI-308C |
| Radial Dynamic Load Capacity (lb): | 15, 320 | Speed (Max): | 1500 |
| Misalignment: | ±3.0° Misalignment - Static Only | Locking Type: | Double Collar Mount |
| Bore Shape: | Straight | Duty Series: | Standard |
| Relubricatable: | Yes | Outer Ring Land Profile: | Standard |
| End Cap: | No | Misalignment Type: | Static Only |
| Replaceable Insert: | Yes | Bearing Insert Coating: | Uncoated |
| Retainer Material: | Steel | Housing Color: | Gray |
| Platform: | RPB Series | Series: | SPB |
| Grease Fitting Thread Size: | 1/8 NPT | UPC: | 662288491835 |
| Weight: | 65.60 LB | Packaged Length: | 16.5 Inches |
| Packaged Width: | 6.75 Inches | Packaged Height: | 9.63 Inches |
| HTC: | 8483.20.8080 | Country of Origin: | United States of America |
