- Powder coated epoxy cast iron housing with extended inner ring bearings
- Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
- Single lip contact seal
- Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
SF-27C
Sealmaster Mounted Cast Iron Four Bolt Flange Ball Bearing – 52100 Bearing Steel, Black Oxided – Setscrew Lock – SF-27C
$218.40
Out of stock
Out of stock
| Rolling Element: | Ball Bearing | Insert Material: | 52100 Bearing Steel, Black Oxided |
|---|---|---|---|
| Housing Base: | Solid | Maximum Operating Temperature: | 220 °F |
| Insert No.: | 2-111C | Duty Series: | Standard Duty |
| Expansion: | No | Retainer Type: | Land Riding Retainer |
| Inner-Race Heat-Treat Method: | Zone-Hardened | Measure Units: | Inch |
| Bore Shape: | Straight | Seal Type: | Single Lip Contact Seal |
| Housing Material: | Cast Iron | Housing Type: | Flange, Four Bolt |
| Pilot Configuration: | No Pilot | Relubricatable: | Yes |
| Locking Type: | Setscrew | Housing Construction: | One Piece |
| Speed (Max): | 3800 | Lubrication: | Lithium Complex NLGI 2 Grease |
| Misalignment: | ±2.0° Misalignment - Static Only | Internal Clearance: | Standard |
| Platform: | Gold Line Ball Bearing | Misalignment Type: | Static Only |
| End Cap: | No | Outer Ring Land Profile: | Standard |
| Bearing Insert Coating: | Black Oxide Coated | Replaceable Insert: | Yes |
| Housing Color: | Gray | T Core: | 3.875 |
| UPC: | 662461022047 | Weight: | 5.70 LB |
| Packaged Length: | 6.06 Inches | Packaged Width: | 5.94 Inches |
| Packaged Height: | 2.19 Inches | HTC: | 8483.20.4040 |
| Country of Origin: | United States of America |
