- Powder coated epoxy cast iron housing with extended inner ring bearings
- Zone hardened inner ring with 120? spacing setscrew locking with diamond faceted setscrews
- Single lip contact seal with black oxide bearing races
- Unique land riding retainer design provides superior pocket clearance that allows for 360? grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Sealmaster? exclusive lock pin , dimple for direct lubrication and anti-rotation
SF-22C
Sealmaster Mounted Cast Iron Four Bolt Flange Ball Bearing – 52100 Bearing Steel, Black Oxided – Setscrew Lock – SF-22C
$160.34
Out of stock
Out of stock
| Maximum Operating Temperature: | 220 °F | Bore Shape: | Straight |
|---|---|---|---|
| Measure Units: | Inch | Inner-Race Heat-Treat Method: | Zone-Hardened |
| Duty Series: | Standard Duty | Rolling Element: | Ball Bearing |
| Insert Material: | 52100 Bearing Steel; Black Oxided | Retainer Type: | Land Riding Retainer |
| Expansion: | No | Insert No.: | 2-16 |
| Housing Base: | Solid | Housing Type: | Flange; Four Bolt |
| Housing Material: | Cast Iron | Seal Type: | Single Lip Contact Seal |
| Pilot Configuration: | No Pilot | Relubricatable: | Yes |
| Speed (Max): | 4650 | Lubrication: | Lithium Complex NLGI 2 Grease |
| Housing Construction: | One Piece | Misalignment: | ±2.0° Misalignment - Static Only |
| Internal Clearance: | Standard | Locking Type: | Setscrew |
| Housing Color: | Gray | Outer Ring Land Profile: | Standard |
| Replaceable Insert: | Yes | Platform: | Gold Line Ball Bearing |
| Bearing Insert Coating: | Black Oxide Coated | Misalignment Type: | Static Only |
| End Cap: | No | T Core: | 3.3125 |
| UPC: | 662461021996 | Weight: | 3.73 LB |
| Packaged Length: | 5 Inches | Packaged Width: | 2 Inches |
| Packaged Height: | 5 Inches | HTC: | 8483.20.4040 |
| Country of Origin: | United States of America |
