- Large Selection – MVP companion sheaves are offered in A/B, C, 5V & 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
- Statically Balanced – All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
- VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
- The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
- When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
- When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.
4MVP70B84X 2 1/8
Browning 4 Groove Cast Iron Finished Bore Multiple Variable Pitch Sheave – 4MVP70B84X 2 1/8
$1,511.80
Out of stock
Out of stock
| Face Width (Max) (in): | 4.5625 in | Outside Diameter (in): | 8.68 in |
|---|---|---|---|
| Pitch Diameter Range (B): | 8.7 - 7.3 | Number of Grooves: | 4 |
| Ring: | 5.375 | Type of Bore: | Finished |
| Material: | Cast Iron | Pitch Diameter Range (A): | 8.2 - 7.1 |
| Outside Length (in): | 5.875 in | Face Width (Min) (in): | 4.1875 in |
| Product Type: | MVP Sheaves | Belt Section: | A, B |
| Bore (in): | 2.125 in | Bore Type: | Finished with Keyway and SS |
| Keyway Size: | .500 | Set Screw Tightening Torque (in-lb): | 290 |
| Set Screw Thread: | 3/8-16 UNC-3AX5/8 | UPC: | 662289332571 |
| Weight: | 46.20 LB | Packaged Length: | 9.20 Inches |
| Packaged Width: | 9.20 Inches | Packaged Height: | 8.90 Inches |
| HTC: | 8483.50.9040 | Country of Origin: | United States of America |
