- Close Grain Cast iron – Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
35V520SDS
Browning 3 Groove Cast Iron Bushed Bore Multiple Sheave – 35V520SDS
$303.85
Out of stock
Out of stock
| Material: | Cast Iron | Model Name: | 35V_LG_Sheavemaster |
|---|---|---|---|
| Pitch Diameter (5V): | 5.1 | Number of Grooves: | 3 |
| Pulley Material: | Cast Iron | Outside Diameter (in): | 5.2 in |
| Bushing Used: | SDS | Product Type: | Multiple Sheaves |
| Bore (Min) (in): | 0.5 in | Belt Section: | 5V |
| Bore Type: | QD Bushed | Number of Hubs: | 1 |
| Face Width (in): | 2.375 | Overall Width (in): | 2.375 |
| Pulley Construction: | Solid | Bushing Bore Range: | .500 - 2.000 |
| UPC: | 662289468911 | Weight: | 5.86 LB |
| Packaged Length: | 6.06 Inches | Packaged Width: | 6.06 Inches |
| Packaged Height: | 2.50 Inches | HTC: | 8483.50.9040 |
| Country of Origin: | Mexico |
