- Incorporates Browning Split Taper Bushing – The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
- Sheaves are Statically Balanced – All sheaves are statically balanced to assure smooth, vibration free performance.
- Close Grain Cast iron – Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
2H3V56
Browning 2 Groove Cast Iron Bushed Bore Multiple Sheave – 2H3V56
$210.17
Out of stock
Out of stock
| Bushing Used: | H | Pulley Material: | Cast Iron |
|---|---|---|---|
| Material: | Cast Iron | Number of Grooves: | 2 |
| Pitch Diameter (3V): | 5.55 | Overall Length (in): | 1.5 in |
| Outside Diameter (in): | 5.6 in | Bore (Min) (in): | 0.375 in |
| Product Type: | Multiple Sheaves | Belt Section: | 3V |
| Bore Type: | Split Taper Bushed | Overall Width (in): | 1.5 |
| Face Width (in): | 1.0938 | Pulley Construction: | Plain |
| Bushing Bore Range: | 0.375 - 1.500 | UPC: | 662289239702 |
| Weight: | 3.40 LB | Packaged Length: | 6.56 Inches |
| Packaged Width: | 6.56 Inches | Packaged Height: | 1.31 Inches |
| HTC: | 8483.50.9040 | Country of Origin: | Mexico |
