- Unmatched Quality and Performance in Morse Brand Chain
- Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
- Available from Stock
100 C/L C/P S/F
Morse Standard Roller Chain Cotter Pin Connecting Link – 100 C/L C/P S/F
$7.63
Out of stock
Out of stock
| Roller Width (in): | 0.75 in | Centerline to Opposite cotter Pin Side: | 0.778 |
|---|---|---|---|
| Chain Size: | 100 | Side Plate Cfg.: | Hourglass |
| Connecting Link - Slip Fit: | Cotter | Roller Diameter (in): | 0.75 in |
| Plate Thickness: | 0.156 | Number of Strands/Width: | 1 |
| Pin Diameter (in): | 0.375 in | Centerline to Outside of cotter Pin: | 0.923 |
| Width Over Pins/Total Width: | 1.555 | Inside Plate Height: | 1.166 |
| Average Ultimate Tensile Strength (psi): | 24, 000 | Number of Connecting Links Included: | 5 |
| Material: | Steel | Product Type: | Roller Chain |
| Chain Pitch (in): | 1.25 in | Chain Type: | Standard |
| Chain Construction: | Cottered | Link Type: | Connecting Link |
| UPC: | 662288468387 | Weight: | 0.26 LB |
| Packaged Length: | 3.85 Inches | Packaged Width: | 3.30 Inches |
| Packaged Height: | 1.55 Inches | HTC: | 7315.19.0000 |
| Country of Origin: | Taiwan, Republic of China |
