USFBE5000KE-215-C
Sealmaster Mounted Ductile Iron Four Bolt Flange Spherical Roller – 52100 Bearing Steel, Black Oxided – Adapter Mount Lock – USFBE5000KE-215-C
$3,227.46
Out of stock
Out of stock
| Housing Type: | Flange, Four Bolt | Platform: | USRB |
|---|---|---|---|
| Grease Fitting Thread Size: | 1/8 NPT | Housing Color: | Gray |
| Misalignment Type: | Dynamic | Insert Number: | USI5000K-215-C |
| Speed [Max] (RPM): | 1600 rpm | Lubrication Method: | Lubrication Fitting |
| Misalignment: | ±2.0° Misalignment - Dynamic | Bearing Insert Coating: | Black Oxide Coated |
| End Cap: | No | Rolling Element: | Spherical Roller |
| Bore Shape: | Straight | Insert Material: | 52100 Bearing Steel, Black Oxided |
| Replaceable Insert: | No | Measure Units: | Inch |
| Housing Material: | Ductile Iron | Pilot Configuration: | No Pilot |
| Outer Ring Land Profile: | Standard | Housing Construction: | Solid |
| Seal Type: | Multi-Lip Contact Seal | Series: | USFBE5000 |
| Lubrication Type: | Lithium Complex NLGI 2 Grease | Bolt Hole Shape: | Round Hole |
| Radial Dynamic Load Capacity (lb): | 47, 447 lb | Ability to Relubricate: | Yes |
| Locking Type: | Adapter Mount | Radial Static Load Capacity (lb): | 65, 610 lb |
| Housing Style: | Flange Block | Retainer: | Steel |
| Clearance: | Standard | Fixed vs. Expansion: | Expansion |
| UPC: | 662461412954 | Weight: | 18.70 LB |
| Packaged Length: | 11.19 Inches | Packaged Width: | 11 Inches |
| Packaged Height: | 4.88 Inches | HTC: | 8483.20.4080 |
| Country of Origin: | United States of America |
