USFBE5000K-208
Sealmaster Mounted Ductile Iron Four Bolt Flange Spherical Roller – 52100 Bearing Steel, Black Oxided – Adapter Mount Lock – USFBE5000K-208
Out of stock
| Measure Units: | Inch | Outer Ring Land Profile: | Standard |
|---|---|---|---|
| Insert Material: | 52100 Bearing Steel, Black Oxided | Housing Material: | Ductile Iron |
| Housing Construction: | Solid | Misalignment Type: | Dynamic |
| Lubrication Type: | Lithium Complex NLGI 2 Grease | Bearing Insert Coating: | Black Oxide Coated |
| Housing Type: | Flange, Four Bolt | Seal Type: | Felt Labyrinth Seal |
| Rolling Element: | Spherical Roller | Lubrication Method: | Lubrication Fitting |
| Replaceable Insert: | No | Misalignment: | ±2.0° Misalignment - Dynamic |
| End Cap: | No | Insert Number: | USI5000K-208 |
| Housing Color: | Gray | Bore Shape: | Straight |
| Pilot Configuration: | No Pilot | Platform: | USRB |
| Series: | USFBE5000 | Speed [Max] (RPM): | 3250 rpm |
| Grease Fitting Thread Size: | 1/8 NPT | Ability to Relubricate: | Yes |
| Fixed vs. Expansion: | Fixed | Radial Dynamic Load Capacity (lb): | 44, 691 lb |
| Clearance: | Standard | Retainer: | Steel |
| Locking Type: | Adapter Mount | Bolt Hole Shape: | Round Hole |
| Housing Style: | Flange Block | Radial Static Load Capacity (lb): | 59, 535 lb |
| UPC: | 662461416617 | Weight: | 20.01 LB |
| Packaged Length: | 7.88 Inches | Packaged Width: | 7.75 Inches |
| Packaged Height: | 4.69 Inches | HTC: | 8483.20.4080 |
| Country of Origin: | Mexico |
