- Reinforced black polyamide housing.
- 400 series stainless steel setscrew locking bearing insert.
- Includes yellow open end cap with seal and O-ring, and back side housing seal.
UCFH208-40M-SS-OEC
System Plast Mounted Polyamide Three Bolt Flange Ball Bearing – 400 Series Stainless Steel – Setscrew Lock – Open End Cap/Back Seal included – UCFH208-40M-SS-OEC
Out of stock
| Housing Material: | Polyamide | Duty Series: | Standard Duty |
|---|---|---|---|
| Rolling Element: | Ball Bearing | Housing Base: | Solid |
| Expansion: | No | Retainer Type: | Ball Riding Retainer |
| Internal Clearance: | Standard | Insert No.: | SS-SB208-40M RG |
| Measure Units: | Metric | Speed (Max): | 2200 |
| Misalignment: | ±1.0° Misalignment - Static Only | Bore Shape: | Straight |
| Housing Type: | Flange, Two Bolt | Seal Type: | Single Lip Contact Seal |
| Relubricatable: | Yes | Housing Construction: | One Piece |
| Maximum Operating Temperature: | 180 °F | Lubrication: | NSF H1 Food Grade Grease |
| Radial Dynamic Load Capacity (lb): | 3, 777 | Locking Type: | Setscrew |
| Insert Material: | 400 Series Stainless Steel | Retainer Material: | Stainless Steel Riveted |
| Misalignment Type: | Static Only | End Cap: | Yes |
| Bearing Insert Coating: | Uncoated | Platform: | System Plast |
| Housing Color: | Black | Replaceable Insert: | No |
| Outer Ring Land Profile: | Standard | Radial Static Load Capacity (lb): | 3, 012 |
| UPC: | 787405584051 | Weight: | 1.76 LB |
| Packaged Length: | 6.89 Inches | Packaged Width: | 3.94 Inches |
| Packaged Height: | 2.57 Inches | HTC: | 8483.20.4040 |
| Country of Origin: | China |
