TB-32R

Powder coated epoxy cast iron housing with extended inner ring bearings
Zone hardened inner ring with 120? spacing setscrew with diamond faceted setscrews
Unique land riding retainer design provides superior pocket clearance that allows for 360? grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Sealmaster? exclusive lock pin , dimple for direct lubrication and anti-rotation

Housing Base:	Solid	Speed (Max):	3550
Housing Type:	Pillow Block; Tapped Base	Maximum Operating Temperature:	220 °F
Seal Type:	Felt Labyrinth Seal	Housing Material:	Cast Iron
Insert No.:	1-2	Rolling Element:	Ball Bearing
Duty Series:	Standard Duty	Retainer Type:	Land Riding Retainer
Expansion:	No	Insert Material:	52100 Bearing Steel; Black Oxided
Measure Units:	Inch	Radial Dynamic Load Capacity (lb):	7, 889
Internal Clearance:	Standard	Locking Type:	Setscrew
Lubrication:	Lithium Complex NLGI 2 Grease	Misalignment:	±2.0° Misalignment - Static Only
Set Screw Thread:	3/8-24 UNF X .31	Relubricatable:	Yes
Bore Shape:	Straight	Housing Construction:	One Piece
Inner-Race Heat-Treat Method:	Zone-Hardened	Misalignment Type:	Static Only
End Cap:	No	Outer Ring Land Profile:	Standard
Replaceable Insert:	Yes	Bearing Insert Coating:	Black Oxide Coated
Platform:	Gold Line Ball Bearing	Housing Color:	Gray
Radial Static Load Capacity (lb):	5, 216	Grease Fitting Thread Size:	1/4-28
UPC:	662461007327	Weight:	7.03 LB
Packaged Length:	5.94 Inches	Packaged Width:	6.06 Inches
Packaged Height:	2.19 Inches	HTC:	8483.20.8040
Country of Origin:	United States of America
