SFC-23TC CTY
Sealmaster Mounted Cast Iron Flange Cartridge Ball Bearing – 52100 Bearing Steel, Black Oxided – Concentric Lock – SFC-23TC CTY
Out of stock
| Locking Type: | Concentric | Operating Temperature Range: | Max. +220°F |
|---|---|---|---|
| Misalignment Type: | Static Only | Maximum Operating Temperature: | 220 °F |
| Options: | Plug | Radial Dynamic Load Capacity (lb): | 5, 782 |
| Relubricatable: | No | Insert Material: | 52100 Bearing Steel, Black Oxided |
| Housing Construction: | One Piece | Housing Type: | Flange, Piloted |
| Platform: | Gold Line Ball Bearing | Seal Type: | Single Lip Contact Seal |
| Rolling Element: | Ball Bearing | Pilot Configuration: | No Pilot |
| End Cap: | No | Replaceable Insert: | Yes |
| Outer Ring Land Profile: | Standard | Misalignment: | ±2.0° Misalignment - Static Only |
| Retainer Type: | Land Riding Retainer | Housing Material: | Cast Iron |
| Lubrication: | Lithium Complex NLGI 2 Grease | Speed (Max): | 4650 |
| Housing Color: | Gray | Expansion: | No |
| Radial Static Load Capacity (lb): | 3, 493 | Bearing Insert Coating: | Black Oxide Coated |
| Measure Units: | Inch | Housing Base: | Solid |
| Bore Shape: | Straight | Insert No.: | 2-17TC SFB |
| Inner-Race Heat-Treat Method: | Zone-Hardened | Duty Series: | Standard Duty |
| Internal Clearance: | Standard | UPC: | 662461210413 |
| Weight: | 4.20 LB | Packaged Length: | 5 Inches |
| Packaged Width: | 2 Inches | Packaged Height: | 5 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | United States of America |
