- Powder coated epoxy cast iron housing with extended inner ring bearings
- Zone hardened inner ring with 120? spacing setscrew locking with diamond faceted setscrews
- Felt labyrinth seal and flinger for dry , dusty environment
- Unique land riding retainer design provides superior pocket clearance that allows for 360? grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Sealmaster? exclusive lock pin , dimple for direct lubrication and anti-rotation
SF-208
Sealmaster Mounted Cast Iron Four Bolt Flange Ball Bearing – 52100 Bearing Steel, Black Oxided – Setscrew Lock – SF-208
$203.85
Out of stock
Out of stock
| Measure Units: | Metric | Insert Material: | 52100 Bearing Steel; Black Oxided |
|---|---|---|---|
| Expansion: | No | Inner-Race Heat-Treat Method: | Zone-Hardened |
| Housing Material: | Cast Iron | Maximum Operating Temperature: | 220 °F |
| Housing Type: | Flange; Four Bolt | Housing Base: | Solid |
| Bore Shape: | Straight | Seal Type: | Felt Labyrinth Seal |
| Rolling Element: | Ball Bearing | Retainer Type: | Land Riding Retainer |
| Duty Series: | Standard Duty | Insert No.: | 5208 |
| Relubricatable: | Yes | Pilot Configuration: | No Pilot |
| Speed (Max): | 4150 | Locking Type: | Setscrew |
| Misalignment: | ±2.0° Misalignment - Static Only | Internal Clearance: | Standard |
| Lubrication: | Lithium Complex NLGI 2 Grease | Housing Construction: | One Piece |
| Misalignment Type: | Static Only | Platform: | Gold Line Ball Bearing |
| Bearing Insert Coating: | Black Oxide Coated | End Cap: | No |
| Replaceable Insert: | Yes | Outer Ring Land Profile: | Standard |
| Housing Color: | Gray | T Core: | 3.5 |
| UPC: | 662461052297 | Weight: | 4.95 LB |
| Packaged Length: | 5.5 Inches | Packaged Width: | 2.13 Inches |
| Packaged Height: | 5.5 Inches | HTC: | 8483.20.4040 |
| Country of Origin: | Mexico |
