- Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
- Race-mounted contact flinger seal
- Double-collar interlock with 120? spacing setscrew lock, diamond faceted setscrews
- Fluoropolymer-coated 4-bolt split cast iron housing for improved corrosion resistance
- USDA H-1 approved Food-grade grease
RPB 407-C4 CR
Sealmaster Mounted Flouropolymer Coated Cast Iron Four Bolt Pillow Block Tapered Roller – 52100 Bearing Steel – Double Collar Mount Lock – Corrosion Resistant – RPB 407-C4 CR
$4,878.99
Out of stock
Out of stock
| Seal Type: | Single Lip Contact Seal | Inner-Race Heat-Treat Method: | Case Carburized Inner Ring |
|---|---|---|---|
| Measure Units: | Inch | Housing Type: | Pillow Block; Four Bolt |
| Expansion: | No | Rolling Element: | Tapered Roller |
| Housing Material: | Flouropolymer Coated Cast Iron | Housing Base: | Solid |
| Insert Material: | 52100 Bearing Steel | Maximum Operating Temperature: | 220 °F |
| Insert No.: | RCI-407C FG1 | Locking Type: | Double Collar Mount |
| Duty Series: | Standard | Bore Shape: | Straight |
| Speed (Max): | 1250 | Radial Dynamic Load Capacity (lb): | 25, 750 |
| Housing Construction: | Split Two Piece | Relubricatable: | Yes |
| Lubrication: | Lithium; EP; NLGI#2 | Misalignment: | ±3.0° Misalignment - Static Only |
| Internal Clearance: | Standard | Replaceable Insert: | Yes |
| Platform: | CR Series | Housing Color: | Silver/Gray |
| End Cap: | No | Bearing Insert Coating: | Uncoated |
| Options: | Corrosion Resistant | Misalignment Type: | Static Only |
| Outer Ring Land Profile: | Standard | Retainer Material: | Steel |
| Series: | RPB | Grease Fitting Thread Size: | 1/8 NPT |
| UPC: | 662288745624 | Weight: | 95.60 LB |
| Packaged Length: | 16.5 Inches | Packaged Width: | 6.75 Inches |
| Packaged Height: | 9.63 Inches | HTC: | 8483.20.8080 |
| Country of Origin: | United States of America |
