- Browning Split Taper Bushed Spur Gears are shaft ready and eliminate costly reworking of minimum bore gears
- Helical Gears are quieter than spur gears and give maximum smoothness on parallel shafts
- Browning Gears are rated in accordance with AGMA standards
- When you think “Special” Gears – Think Browning
NCG852
Browning Steel Minimum Plain Bore Change Gear – 14.5 PA 8 DP – NCG852
Out of stock
| Face Width (in): | 1.25 in | Pressure Angle: | 14.5 |
|---|---|---|---|
| Outside Diameter (in): | 6.75 in | Material: | Steel |
| Pitch Diameter (in): | 6.5 in | Number of Teeth/Threads: | 52 |
| Diametral Pitch: | 8 | Bore (Min) (in): | 1.125 in |
| Length Through Bore (in): | 1.25 in | Bore Type: | Minimum Plain Bore |
| Bore (Max) (in): | 1.375 in | Hub Type: | Type A |
| Product Type: | Change Gear | Bore Size (in): | 1.125 in |
| Gear Construction: | Plain | UPC: | 662289101962 |
| Weight: | 11.18 LB | Packaged Length: | 7.06 Inches |
| Packaged Width: | 7.06 Inches | Packaged Height: | 1.56 Inches |
| HTC: | 8483.40.9000 | Country of Origin: | Mexico |
