- Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
- This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
- KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.
KK25-2GD 1K
Morse KK Series CAM Clutch – KK25-2GD 1K
$1,739.81
Out of stock
Out of stock
| Static Radial Load Rating (lb): | 1416.3 | Overall Diameter (in): | 2.047 in |
|---|---|---|---|
| RPM Max. -inner Race: | 2, 500 | Mounting Shaft Diameter: | 0.9839/0.9831 |
| Overall Width (in): | 0.787 in | RPM Max. - Outer Race: | 1400 |
| Dynamic Radial Load Rating (lb): | 2405.5 | Corner Radius: | 1 |
| Type: | CAM Clutches | Overall Diameter (mm): | 52 mm |
| Mounting Housing Diameter: | 2.0466/2.0459 | Add'l Bearing Support Requirement: | No |
| Indexing Clutch: | Yes | Bore Size (mm): | 25 mm |
| Product Type: | KK Series | Backstopping Clutch: | Yes |
| Rated Torque Capacity (ft.-lbs.): | 57.5 | Overrunning Clutch: | Yes |
| UPC: | 662288927488 | Weight: | 0.46 LB |
| Packaged Length: | 2.60 Inches | Packaged Width: | 2.50 Inches |
| Packaged Height: | 1.20 Inches | HTC: | 8483.60.4040 |
| Country of Origin: | Japan |
