- This Product has the Browning Exclusive Twice the Life Guarantee
- Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.
H6020X1
Browning Steel Finished Bore Roller Chain Sprocket – H6020X1
Out of stock
| Chain Pitch (in): | 0.75 in | Material: | Steel, Hardened Teeth |
|---|---|---|---|
| Chain Used: | No. 60, 3/4 in. Pitch ANSI Chain | Number of teeth: | 20 |
| Pitch Diameter (in): | 4.794 in | Print Revision Level: | L |
| Product Type: | Finished Bore Roller Chain Sprocket | Bore Type: | Finished Bore |
| Outside Diameter (in): | 5.185 in | Number of Strands/Width: | 1 |
| Bore (in): | 1 in | Length Through Bore (in): | 1.25 in |
| Hub Diameter (in): | 3.891 in | Tooth Width (in): | 0.459 in |
| Hub Type: | Type B | Hub Projection (in): | 0.796875 in |
| Hardened Teeth: | With Hardened Teeth | Keyway Size: | 1/4 x 1/8 |
| Pitch Type: | Single | UPC: | 662289224395 |
| Weight: | 4.40 LB | Packaged Length: | 6.06 Inches |
| Packaged Width: | 6.06 Inches | Packaged Height: | 1.56 Inches |
| HTC: | 8483.90.1050 | Country of Origin: | United States of America |
