- Lifetime Warranty – If this bushing ever fails Browning will replace it Free of charge.
- Solid Flange, Double Split Barrel – Assures better concentricity to the shaft.
- 3/4″ per Foot Taper on Barrel – Self locking taper provides the highest degree of mechanical locking product to product.
G 14 MM
Browning Split Taper Bushing – Metric Bore Type – G 14 MM
$23.95
Out of stock
Out of stock
| Compatible Bore Size [Max] (mm): | 14 mm | Wrench Torque (in-lb): | 95 |
|---|---|---|---|
| Total Length (in): | 1 in | Model Name: | G_Bushing_Master |
| Total Length (mm): | 25.4 mm | Cap Screws (Size): | 1/4 x 5/8 |
| Keyseat (mm): | 5 x 2.5 mm | Length Through Bore (mm): | 25.4 mm |
| Bushing Type: | G | Outside Diameter (in): | 2 in |
| Material: | Sintered Steel or Ductile Iron | Product Type: | Split Taper Bushing |
| Bore Size (mm): | 14 mm | Outside Diameter (mm): | 50.8 mm |
| Cap Screws (No.): | 2 | Bore Type: | Metric |
| Mounting Type: | Conventional | Flange Type: | Solid Flange |
| Barrel Diameter (Large End): | 1.172 | Thread Size: | 1/4-20 |
| Screw Length: | 0.625 | Flange Thickness: | 0.25 |
| Includes: | Cap Screws | Barrel Diameter (Small End): | 1.133 |
| Bolt Circle Diameter (in): | 1.5625 | UPC: | 662289381401 |
| Weight: | 0.40 LB | Packaged Length: | 2.8 Inches |
| Packaged Width: | 2.6 Inches | Packaged Height: | 1.4 Inches |
| HTC: | 8483.90.8080 | Country of Origin: | Mexico |
