- High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
- High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
- High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
- Solid construction with machined base was designed for minimal gaps and no fillers
- Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
- Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
- Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
- USDA H1 complaint food grade grease
CRPC-PN23T RMW
Sealmaster Mounted Composite Two Bolt Pillow Block Ball Bearing – 52100 Bearing Steel, Phosphorus Nickel Coated – Concentric Lock – Corrosion Resistant – Reduced Maintenance – Lubed for Life – CRPC-PN23T RMW
$939.30
Out of stock
Out of stock
| Expansion: | No | Maximum Operating Temperature: | 220 °F |
|---|---|---|---|
| Speed (Max): | 2000 | Housing Material: | Composite |
| Housing Base: | Solid | Insert Material: | 52100 Bearing Steel, Phosphorus Nickel Coated |
| Insert No.: | PN-23T | Seal Type: | Multi-Lip Contact Seal |
| Duty Series: | Standard Duty | Retainer Type: | Land Riding Retainer |
| Measure Units: | Inch | Rolling Element: | Ball Bearing |
| Internal Clearance: | Standard | Housing Type: | Pillow Block, Two Bolt |
| Radial Dynamic Load Capacity (lb): | 5, 782 | Misalignment: | ±2.0° Misalignment - Static Only |
| Lubrication: | Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease | Bore Shape: | Straight |
| Relubricatable: | No | Housing Construction: | One Piece |
| Inner-Race Heat-Treat Method: | Zone-Hardened | Locking Type: | Concentric |
| Outer Ring Land Profile: | Tapered Lands | Bearing Insert Coating: | Phosphorus Nickel Coated |
| End Cap: | Yes | Housing Color: | Light Gray |
| Replaceable Insert: | Yes | Options: | Corrosion Resistant - Reduced Maintenance - Lubed for Life |
| Misalignment Type: | Static Only | Platform: | PN Gold |
| Certifications: | IP69K | Radial Static Load Capacity (lb): | 3, 493 |
| Cage Material: | PPS | Grease Fitting Thread Size: | 1/4-28 NF |
| UPC: | 662461355312 | Weight: | 1.97 LB |
| Packaged Length: | 4.38 Inches | Packaged Width: | 2.06 Inches |
| Packaged Height: | 6.81 Inches | HTC: | 8483.20.8040 |
| Country of Origin: | United States of America |
