- High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
- High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
- Fluoropolymer coated cast iron housing for corrosion resistance.
- Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
- Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
- Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
- USDA H1 complaint food grade grease
CRPLF-PN27 RMW
Sealmaster Mounted Flouropolymer Coated Cast Iron Two Bolt Pillow Block Ball Bearing – 52100 Bearing Steel, Phosphorus Nickel Coated – Setscrew Lock – Corrosion Resistant – Reduced Maintenance – Lubed for Life – CRPLF-PN27 RMW
$2,619.02
Out of stock
Out of stock
| Housing Base: | Solid | Measure Units: | Inch |
|---|---|---|---|
| Internal Clearance: | Standard | Seal Type: | Multi-Lip Contact Seal |
| Insert Material: | 52100 Bearing Steel, Phosphorus Nickel Coated | Rolling Element: | Ball Bearing |
| Radial Dynamic Load Capacity (lb): | 7, 901 lb | Housing Construction: | One Piece |
| Bore Shape: | Straight | Misalignment: | ±2.0° Misalignment - Static Only |
| Replaceable Insert: | Yes | Housing Color: | Silver/Gray |
| Options: | Corrosion Resistant - Reduced Maintenance - Lubed for Life | Misalignment Type: | Static Only |
| Bearing Insert Coating: | Phosphorus Nickel Coated | Outer Ring Land Profile: | Tapered Lands |
| Platform: | PN Gold | End Cap: | No |
| Certifications: | IP69K | Radial Static Load Capacity (lb): | 5, 139 lb |
| Cage Material: | PPS | Locking Type: | Setscrew |
| Lubrication Type: | Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease | Housing Style: | Pillow Block |
| Duty/Series: | Standard Duty | Retainer Type: | Land Riding Retainer |
| Fixed vs. Expansion: | Fixed | Housing Material: | Flouropolymer Coated Cast Iron |
| Housing Type: | Pillow Block, Two Bolt | Maximum Speed (RPM): | 1600 rpm |
| Insert Number: | PN-27 | Maximum Operating Temperature (F): | 220 °F |
| Ability to Relubricate: | No | Inner Race Heat Treat Method: | Zone-Hardened |
| UPC: | 662461000000 | Weight: | 6.20 LB |
| Packaged Length: | 5.19 Inches | Packaged Width: | 2.13 Inches |
| Packaged Height: | 7.81 Inches | HTC: | 8483.20.8040 |
| Country of Origin: | United States of America |
