- Incorporates Browning Split Taper Bushing – The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
- Sheaves are Statically Balanced – All sheaves are statically balanced to assure smooth, vibration free performance.
- Close Grain Cast iron – Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
8S8V132
Browning 8 Groove Cast Iron Bushed Bore Multiple Sheave – 8S8V132
$3,929.68
Out of stock
Out of stock
| Bushing Used: | S2 | Overall Length (in): | 9.375 in |
|---|---|---|---|
| Pitch Diameter (8V): | 13 | Pulley Material: | Cast Iron |
| Material: | Cast Iron | Outside Diameter (in): | 13.2 in |
| Number of Grooves: | 8 | Bore (Min) (in): | 1.875 in |
| Belt Section: | 8V | Product Type: | Multiple Sheaves |
| Bore Type: | Split Taper Bushed | Keyway Size: | .750 |
| Bushing Bore Range: | 1.8750 - 4.1875 | UPC: | 662289271689 |
| Weight: | 176.00 LB | Packaged Length: | 13.20 Inches |
| Packaged Width: | 13.20 Inches | Packaged Height: | 9.38 Inches |
| HTC: | 8483.50.9040 | Country of Origin: | Mexico |
