- Incorporates Browning Split Taper Bushing – The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
- Combination Groove – All Browning B Sheaves permit the running of A& B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
- Close Grain Cast iron – Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
6B70R
Browning 6 Groove Cast Iron Bushed Bore Multiple Sheave – 6B70R
Out of stock
| Number of Grooves: | 6 | Bushing Used: | R1 |
|---|---|---|---|
| Outside Diameter (in): | 7.35 in | Datum Diameter (A): | 6.6 |
| Datum Diameter (B): | 7 | Overall Length (in): | 4.75 in |
| Material: | Cast Iron | Pulley Material: | Cast Iron |
| Pitch Diameter (B): | 7.3 | Pitch Diameter (A): | 6.8 |
| Bore (Min) (in): | 1.125 in | Product Type: | Multiple Sheaves |
| Belt Section: | A, B | Bore Type: | Split Taper Bushed |
| Face Width (in): | 4.75 | Pulley Construction: | Webbed |
| Bushing Bore Range: | 1.125 - 3.750 | Keyway Size: | .750 |
| Overall Width (in): | 4.75 | UPC: | 662289294749 |
| Weight: | 19.76 LB | Packaged Length: | 7.88 Inches |
| Packaged Width: | 7.88 Inches | Packaged Height: | 4.75 Inches |
| HTC: | 8483.50.9040 | Country of Origin: | Mexico |
