- Molded Teeth – Shear resistance teeth designed to provide smooth positive engagement with gearbelt pulleys.
- High Tensile Cord – Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.
- Compression Section – Bonds to belt cords for protections against dirt, grease, oil, ozone, and other environmental hazards.
390H150
Browning Neoprene H Section Gearbelt – 390H150
$189.38
Out of stock
Out of stock
| Belt Section: | H | Product Type: | Gearbelt |
|---|---|---|---|
| Material: | Neoprene | Std Package Quantity: | 1 |
| Outside Length/Diameter (in): | 39 in | Operating Temperature [Max] ?F: | 180 ?F |
| Operating Temperature [Max] ?C: | 82.2 ?C | Pitch Designation (mm): | 12.7 |
| Number of teeth: | 78 | Tooth Profile: | Trapezoidal |
| Standards met: | ARPM IP-24 ISO19347:2032 | Reinforcing cord material: | Fiberglass |
| Color: | Black | Number of toothed sides: | 1 |
| Resistance Features: | Oil & Chemical Resistant per ARPM IP-3-2 | UPC: | 662289120017 |
| Weight: | 0.33 LB | Packaged Length: | 13.3 Inches |
| Packaged Width: | 11.3 Inches | Packaged Height: | 2.85 Inches |
| HTC: | 4010.35.4500 | Country of Origin: | United States of America |
