- Close Coupled disc coupling design with reversible hubs to accommodate various shaft separations.
- Unitized Disc Packs for ease of maintenance.
- HT (High Torque) disc packs for medium duty applications.
- Meet AGMA Class 9 balance off the shelf, may be balanced to AGMA Class 10 or 11.
354 KD 11 SS
Kop-Flex Disc Coupling – Style KD11 – Size 354 – Rough Bore – 354 KD 11 SS
Out of stock
| Total Length (Two Hub Reverse) (in): | 11.5 in | Style: | KD11 |
|---|---|---|---|
| Total Length (One Hub Reverse) (in): | 10 in | Total Length (Std Hub Post) (in): | 8.5 in |
| Outside Diameter (in): | 12.28 in | Configuration: | 2 standard hubs |
| Hub Material: | Carbon Steel | Coupling Size: | 354 |
| Axial Capacity (+/-): | 0.2 | Total WR2 (lb-in2): | 1, 790 psi |
| Bore Type: | Rough Bore | Length Through Bore (in): | 4.12 in |
| Torque [Max] (ft-lb): | 25, 000 ft/lbs | Torque Rating (in-lb): | 150, 000 in/lbs |
| Length Through Bore standard hub (in): | 4.12 in | Disc Shape: | Scalloped |
| Hub Diameter (in): | 5.91 in | Disc Coupling Type: | Close Coupled |
| Bore Size Min (in): | 4.25 in | UPC: | 6, 62384E+11 |
| Weight: | 136.53 LB |
