- Rugged Cast-Iron Housing: Provides maximum strength and dependability.
- High lead angle worm is case hardened, ground and polished.
- Large, Single Row Ball Bearings On Input Shaft: Absorb radial and thrust loads at higher input speeds. Tapered roller bearings are used on output shaft.
- Forged Bronze Worm Gears: Provide optimum balance of Strength and Wear.
325Q180L60
Morse Raider Plus Worm Gear Reducer Cast Iron Single-Reduction Worm Reducer – 325Q180L60
$3,224.20
Out of stock
Out of stock
| Reducer Style: | Standard | Input Bore (C Face): | 1.125 |
|---|---|---|---|
| Motor Frame Size: | 180TC | Efficiency: | 80 |
| Input Keyway (C Face): | 1/4 X 1/8 | Ratio: | 60:1 |
| Thrust Rating - output shaft: | 3410 | Input Speed: | 1750 |
| Shaft Seal Material: | Nitrile | Manufacturer Reducer Size: | 325 |
| Maximum Input HP: | 2.114 hp @ 1750 rpm | Model Code: | 325Q |
| Assembly: | Q-L | Frame Size: | 180TC |
| Output Key: | 5/16 X 2.88 | Ratio Range: | 60:1 |
| Output Shaft Assembly Code: | L | Series Code: | Raider |
| No. of Gear Reductions: | Single | Output Diameter (in): | 1.375 in |
| Input HP @ 1750 RPM: | 1.76 | Service Factor: | 1 |
| Input Style: | C-Face Quill | Reducer: | Worm - Right Angle |
| Output RPM: | 29.1 | Input RPM: | 1, 75 |
| Mounting Style: | No Base | Center Distance (in): | 3.25 |
| Gear Type: | Worm | Product Type: | Worm Speed Reducer |
| Input Diameter (in): | 1.125 in | Output Shaft Direction: | Left |
| Overhung Load Rating (Output Shaft(lb)): | 2, 401 lb | Output Shaft: | Solid Shaft |
| Housing Material: | Cast Iron | Output Torque Rating (in-lb): | 3274 in-lbs @1750 input RPM in/lbs |
| UPC: | 6, 62288E+11 | Weight: | 75.00 LB |
