- Double row spherical rollers
- Outer ring: Spherical raceway
- Inner Ring: 2 spherical raceway
- Axial and radial loads
- Absorb shaft misalignments
23240 CA KC3 W33
Rollway Radial Spherical Roller Bearing – Tapered Bore – 23240 CA KC3 W33
$6,261.10
Out of stock
Out of stock
| Radial Clearance: | C3 | Bore Type: | Tapered |
|---|---|---|---|
| Series: | 23200 | Cage Material: | Brass |
| Angular Misalignment: | 2.5° | Seal Type: | Unsealed |
| Rolling Element: | Spherical Roller | Number of Rows: | 2 |
| Misalignment: | Yes | Static Load Rating (kN): | 1, 580 kN |
| Material: | 52100 Bearing Steel | Platform: | Spherical Radial |
| Full Complement/Caged: | Caged | Speed (Max) Grease (RPM): | 730 rpm |
| Speed (Max) Oil (RPM): | 970 rpm | Duplexing: | No |
| Sealed: | None | Dynamic Load Rating (kN): | 1, 580 kN |
| Mounting Method: | Adapter Mount | UPC: | 637410069206 |
| Weight: | 126.10 LB | Packaged Length: | 14.17 Inches |
| Packaged Width: | 5.04 Inches | Packaged Height: | 14.17 Inches |
| Country of Origin: | China |
