- Largest selection in the Industry – Browning offers the widest range of variable speed sheaves in the market today. One and two Groove product are available in 1.6″ to 8.5″ covering up to 25 horsepower.
- VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
- The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
- When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
- When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.
1VP50X1
Browning 1 Groove Cast Iron Finish Bore FHP Variable Pitch Sheave – 1VP50X1
$146.21
Out of stock
Out of stock
| Bore (in): | 1 in | Turns Open (B or 5L) (For Max PD): | 1 |
|---|---|---|---|
| Turns Open (B or 5L) (For Min PD): | 6 | Turns Open (3L) (For Min PD): | 4 |
| Outside Diameter (in): | 4.75 in | Turns Open (A or 4L) (For Min PD): | 5 |
| Number of Grooves: | 1 | Type of Bore: | Finished |
| Material: | Cast Iron | Belt Section: | 3L, 4L or A, 5L or B |
| Product Type: | FHP Variable Pitch Sheaves | Pitch Diameter (3L) (Max): | 4.1 |
| Pitch Diameter (3L) (Min): | 3.3 | UPC: | 662289265008 |
| Weight: | 3.85 LB | Packaged Length: | 5.00 Inches |
| Packaged Width: | 5.20 Inches | Packaged Height: | 2.40 Inches |
| HTC: | 8483.50.9040 | Country of Origin: | Mexico |
