- Close Grain Cast iron – Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
13V220JA
Browning 1 Groove Cast Iron Bushed Bore Multiple Sheave – 13V220JA
Out of stock
| Bushing Used: | JA | Model Name: | 13V_SM_Sheavemaster |
|---|---|---|---|
| Number of Grooves: | 1 | Material: | Cast Iron |
| Pulley Material: | Cast Iron | Outside Diameter (in): | 2.2 in |
| Pitch Diameter (3V): | 2.15 | Bore (Min) (in): | 0.5 in |
| Product Type: | Multiple Sheaves | Belt Section: | 3V |
| Bore Type: | QD Bushed | Bushing Bore Range: | 0.500 - 1.250 |
| UPC: | 662289468621 | Weight: | 0.72 LB |
| Packaged Length: | 2.56 Inches | Packaged Width: | 2.56 Inches |
| Packaged Height: | 1.38 Inches | HTC: | 8483.50.9040 |
| Country of Origin: | Mexico |
