- Powder coat epoxy cast iron housing
- Zone hardened inner ring with 120° spacing setscrew lock with diamond faceted setscrews
- Single lip contact seal and flinger
VFBS-220
Browning Mounted Cast Iron Three Bolt Flange Bracket Ball Bearing – 52100 Bearing Steel, Black Oxided Inner – Setscrew Lock – VFBS-220
Out of stock
| Housing Base: | Solid | Seal Type: | Single Lip Contact Seal with Flinger |
|---|---|---|---|
| Measure Units: | Inch | Bore Shape: | Straight |
| Rolling Element: | Ball Bearing | Insert Material: | 52100 Bearing Steel, Black Oxided Inner |
| Pilot Configuration: | No Pilot | Housing Construction: | One Piece |
| Misalignment: | ±1.5° Misalignment - Static Only | Internal Clearance: | Standard |
| Radial Dynamic Load Capacity (lb): | 5, 782 lb | End Cap: | No |
| Housing Color: | Gray | Replaceable Insert: | Yes |
| Misalignment Type: | Static Only | Outer Ring Land Profile: | Standard |
| Bearing Insert Coating: | Black Oxide Coated Inner Ring | Retainer Material: | Molded fiber glass reinforced nylon |
| Radial Static Load Capacity (lb): | 3, 493 lb | Maximum Speed (RPM): | 4000 rpm |
| Locking Type: | Setscrew | Lubrication Type: | Lithium Complex NLGI 2 Grease |
| Fixed vs. Expansion: | Fixed | Duty/Series: | Standard Duty |
| Housing Type: | Flange, Bracket, Three Bolt | Retainer Type: | Ball Riding Retainer |
| Housing Style: | Flange Block | Housing Material: | Cast Iron |
| Ability to Relubricate: | Yes | Insert Number: | VS-220 |
| Maximum Operating Temperature (F): | 200 °F | UPC: | 662460495859 |
| Weight: | 1.60 LB | Packaged Length: | 4.38 Inches |
| Packaged Width: | 2.06 Inches | Packaged Height: | 6.81 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | Mexico |
