- Powder coat epoxy cast iron housing
- Zone hardened inner ring with 120? spacing setscrew lock with diamond faceted setscrews
- Single lip contact seal
VF4S-132S
Browning Mounted Cast Iron Four Bolt Flange Ball Bearing – 52100 Bearing Steel – Setscrew Lock – VF4S-132S
$168.66
Availability: 1 in stock
Availability: 1 in stock
| Insert No.: | VS-132S | Inner-Race Heat-Treat Method: | Zone-Hardened |
|---|---|---|---|
| Rolling Element: | Ball Bearing | Maximum Operating Temperature: | 200 °F |
| Housing Base: | Semi-Solid | Housing Type: | Flange; Four Bolt |
| Seal Type: | Single Lip Contact Seal | Expansion: | No |
| Insert Material: | 52100 Bearing Steel | Bore Shape: | Straight |
| Measure Units: | Inch | Duty Series: | Intermediate Duty |
| Retainer Type: | Ball Riding Retainer | Housing Material: | Cast Iron |
| Radial Dynamic Load Capacity (lb): | 7, 889 | Relubricatable: | Yes |
| Pilot Configuration: | No Pilot | Internal Clearance: | Standard |
| Housing Construction: | One Piece | Lubrication: | Lithium Complex NLGI 2 Grease |
| Speed (Max): | 2000 | Misalignment: | ±1.5° Misalignment - Static Only |
| Locking Type: | Setscrew | Bearing Insert Coating: | Uncoated |
| End Cap: | No | Outer Ring Land Profile: | Standard |
| Retainer Material: | Molded fiber glass reinforced nylon | Replaceable Insert: | Yes |
| Misalignment Type: | Static Only | Housing Color: | Gray |
| Radial Static Load Capacity (lb): | 5, 216 | UPC: | 662289314812 |
| Weight: | 5.74 LB | Packaged Length: | 6.4 Inches |
| Packaged Width: | 7 Inches | Packaged Height: | 2.2 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | Mexico |
