- Reinforced white polyamide Nolu-Clean housing with antimicrobial additive.
- 52100 chrome steel setscrew locking ball bearing insert.
UCFH204-20M-NC
System Plast Mounted Nolu-Clean Four Bolt Flange Ball Bearing – 52100 Bearing Steel – Setscrew Lock – UCFH204-20M-NC
Out of stock
| Internal Clearance: | Standard | Housing Material: | Nolu-Clean |
|---|---|---|---|
| Duty Series: | Standard Duty | Housing Base: | Solid |
| Rolling Element: | Ball Bearing | Retainer Type: | Ball Riding Retainer |
| Measure Units: | Metric | Insert No.: | SB204-20M RG |
| Expansion: | No | Locking Type: | Setscrew |
| Misalignment: | ±1.0° Misalignment - Static Only | Radial Dynamic Load Capacity (lb): | 2, 214 |
| Relubricatable: | Yes | Seal Type: | Single Lip Contact Seal |
| Lubrication: | NSF H1 Food Grade Grease | Speed (Max): | 4200 |
| Maximum Operating Temperature: | 180 °F | Bore Shape: | Straight |
| Housing Construction: | One Piece | Housing Type: | Flange, Two Bolt |
| Insert Material: | 52100 Bearing Steel | Replaceable Insert: | No |
| Outer Ring Land Profile: | Standard | Bearing Insert Coating: | Uncoated |
| Misalignment Type: | Static Only | Housing Color: | White |
| End Cap: | Yes | Retainer Material: | Steel Riveted |
| Radial Static Load Capacity (lb): | 1, 479 | UPC: | 726166303563 |
| Weight: | 0.66 LB | Packaged Length: | 3.94 Inches |
| Packaged Width: | 2.2 Inches | Packaged Height: | 1.32 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | China |
