- Powder coated epoxy cast iron housing with extended inner ring bearings
- Skwezloc? concentric locking for near perfect concentricity
- Single lip contact seal
- Unique land riding retainer design provides superior pocket clearance that allows for 360? grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Sealmaster? exclusive lock pin , dimple for direct lubrication and anti-rotation
TFT-22TC-1
Sealmaster Mounted Cast Iron Two Bolt Flange Ball Bearing – 52100 Bearing Steel, Black Oxided – Concentric Lock – TFT-22TC-1
$179.92
Availability: 9 in stock
Availability: 9 in stock
| Seal Type: | Single Lip Contact Seal | Insert No.: | 2-16TC |
|---|---|---|---|
| Housing Material: | Cast Iron | Rolling Element: | Ball Bearing |
| Expansion: | No | Duty Series: | Standard Duty |
| Maximum Operating Temperature: | 220 °F | Measure Units: | Inch |
| Insert Material: | 52100 Bearing Steel; Black Oxided | Housing Base: | Solid |
| Inner-Race Heat-Treat Method: | Zone-Hardened | Retainer Type: | Land Riding Retainer |
| Relubricatable: | Yes | Pilot Configuration: | No Pilot |
| Internal Clearance: | Standard | Speed (Max): | 4650 |
| Lubrication: | Lithium Complex NLGI 2 Grease | Locking Type: | Concentric |
| Bore Shape: | Straight | Housing Type: | Flange; Two Bolt |
| Housing Construction: | One Piece | Misalignment: | ±2.0° Misalignment - Static Only |
| End Cap: | No | Misalignment Type: | Static Only |
| Housing Color: | Gray | Outer Ring Land Profile: | Standard |
| Platform: | Gold Line Ball Bearing | Replaceable Insert: | Yes |
| Bearing Insert Coating: | Black Oxide Coated | UPC: | 662461007907 |
| Weight: | 2.84 LB | Packaged Length: | 5 Inches |
| Packaged Width: | 2 Inches | Packaged Height: | 5 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | United States of America |
