- Powder coated epoxy cast iron housing with extended inner ring bearings
- Zone hardened inner ring with 120? spacing setscrew with diamond faceted setscrews
- Unique land riding retainer design provides superior pocket clearance that allows for 360? grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Sealmaster? exclusive lock pin , dimple for direct lubrication and anti-rotation
SFT-22
Sealmaster Mounted Cast Iron Two Bolt Flange Ball Bearing – 52100 Bearing Steel, Black Oxided – Setscrew Lock – SFT-22
$139.43
Availability: 52 in stock
Availability: 52 in stock
| Housing Base: | Solid | Housing Material: | Cast Iron |
|---|---|---|---|
| Duty Series: | Standard Duty | Inner-Race Heat-Treat Method: | Zone-Hardened |
| Expansion: | No | Measure Units: | Inch |
| Insert Material: | 52100 Bearing Steel; Black Oxided | Rolling Element: | Ball Bearing |
| Retainer Type: | Land Riding Retainer | Insert No.: | 2-16 |
| Maximum Operating Temperature: | 220 °F | Seal Type: | Felt Labyrinth Seal |
| Pilot Configuration: | No Pilot | Relubricatable: | Yes |
| Lubrication: | Lithium Complex NLGI 2 Grease | Housing Construction: | One Piece |
| Locking Type: | Setscrew | Speed (Max): | 4650 |
| Bore Shape: | Straight | Misalignment: | ±2.0° Misalignment - Static Only |
| Housing Type: | Flange; Two Bolt | Radial Dynamic Load Capacity (lb): | 5, 782 |
| Internal Clearance: | Standard | Housing Color: | Gray |
| Outer Ring Land Profile: | Standard | End Cap: | No |
| Replaceable Insert: | Yes | Misalignment Type: | Static Only |
| Platform: | Gold Line Ball Bearing | Bearing Insert Coating: | Black Oxide Coated |
| Radial Static Load Capacity (lb): | 3, 493 | UPC: | 662461004357 |
| Weight: | 3.12 LB | Packaged Length: | 5 Inches |
| Packaged Width: | 2 Inches | Packaged Height: | 5 Inches |
| HTC: | 8483.20.4040 | Country of Origin: | Mexico |
