- Powder coated epoxy cast iron housing with extended inner ring bearings
- Skwezloc? concentric locking for near perfect concentricity
- Felt labyrinth seal and flinger for dry , dusty environment
- Unique land riding retainer design provides superior pocket clearance that allows for 360? grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Sealmaster? exclusive lock pin , dimple for direct lubrication and anti-rotation
SF-22T
Sealmaster Mounted Cast Iron Four Bolt Flange Ball Bearing – 52100 Bearing Steel, Black Oxided – Concentric Lock – SF-22T
$164.91
Availability: 30 in stock
Availability: 30 in stock
| Housing Base: | Solid | Retainer Type: | Land Riding Retainer |
|---|---|---|---|
| Duty Series: | Standard Duty | Expansion: | No |
| Housing Material: | Cast Iron | Bore Shape: | Straight |
| Measure Units: | Inch | Insert Material: | 52100 Bearing Steel; Black Oxided |
| Housing Type: | Flange; Four Bolt | Maximum Operating Temperature: | 220 °F |
| Insert No.: | 2-16T | Seal Type: | Felt Labyrinth Seal |
| Rolling Element: | Ball Bearing | Inner-Race Heat-Treat Method: | Zone-Hardened |
| Radial Dynamic Load Capacity (lb): | 5, 782 | Relubricatable: | Yes |
| Pilot Configuration: | No Pilot | Locking Type: | Concentric |
| Lubrication: | Lithium Complex NLGI 2 Grease | Housing Construction: | One Piece |
| Internal Clearance: | Standard | Misalignment: | ±2.0° Misalignment - Static Only |
| Speed (Max): | 6500 | Housing Color: | Gray |
| Replaceable Insert: | Yes | Bearing Insert Coating: | Black Oxide Coated |
| Outer Ring Land Profile: | Standard | End Cap: | No |
| Misalignment Type: | Static Only | Platform: | Gold Line Ball Bearing |
| T Core: | 3.5 | Radial Static Load Capacity (lb): | 3, 493 |
| UPC: | 662461030028 | Weight: | 4.01 LB |
| Packaged Length: | 2 Inches | Packaged Width: | 5 Inches |
| Packaged Height: | 5 Inches | HTC: | 8483.20.4040 |
| Country of Origin: | Mexico |
