- 22300 series spherical bearing
- Single row separated spherical rolling elements
- Oil hole and annular lubrication groove
- Standard internal clearance
SB 22314 W33
McGill SPHERE-ROL® Radial Spherical Roller Bearing – Straight Bore – Unsealed – SB 22314 W33
$852.42
Out of stock
Out of stock
| Series: | 22300 | Seal Type: | Unsealed |
|---|---|---|---|
| Cage Material: | Steel | Radial Clearance: | C0 |
| Rolling Element: | Spherical Roller | Angular Misalignment: | 3° |
| Material: | 52100 Bearing Steel | Bore Type: | Straight |
| Misalignment: | Yes | Number of Rows: | 1 |
| Speed (Max) Grease (RPM): | 1, 500 rpm | Duplexing: | No |
| Platform: | SPHERE-ROL® | Speed (Max) Oil (RPM): | 3, 000 rpm |
| Full Complement/Caged: | Caged | Sealed: | None |
| Precision Rating: | P0, ISO 15-2042 | Outer Ring Type: | Not split |
| Finish/Coating: | Uncoated | Lubrication Hole Type: | Lubrication Groove & Hole |
| Dynamic Load Rating (kN): | 306.4 kN | Mounting Method: | Shaft Mount |
| Operating Temperature Range (F): | -30 to 300 °F °F | Maximum Operating Temperature (F): | 300 °F |
| UPC: | 726166011086 | Weight: | 9.50 LB |
| Packaged Length: | 7.31 Inches | Packaged Width: | 2.31 Inches |
| Packaged Height: | 7.25 Inches | HTC: | 8482.30.0040 |
| Country of Origin: | United States of America |
