- Browning Change Gears, change gear bushing sold separately
- Browning Gears are rated in accordance with AGMA standards
- When you think “Special” Gears – Think Browning
NCG1668
Browning Steel Minimum Plain Bore Change Gear – 14.5 PA 16 DP – NCG1668
$223.06
Out of stock
Out of stock
| Pitch Diameter (in): | 4.25 in | Face Width (in): | 0.5 in |
|---|---|---|---|
| Material: | Steel | Number of Teeth/Threads: | 68 |
| Pressure Angle: | 14.5 | Outside Diameter (in): | 4.37 in |
| Diametral Pitch: | 16 | Bore Type: | Minimum Plain Bore |
| Length Through Bore (in): | 0.5 in | Bore (Max) (in): | 0.75 in |
| Bore (Min) (in): | 0.75 in | Product Type: | Change Gear |
| Bore Size (in): | 0.75 in | Hub Type: | Type A |
| Standard Met: | AGMA | UPC: | 662289249350 |
| Weight: | 1.98 LB | Packaged Length: | 5.60 Inches |
| Packaged Width: | 5.80 Inches | Packaged Height: | 1.10 Inches |
| HTC: | 8483.40.9000 | Country of Origin: | Mexico |
