- Powder coated epoxy cast iron housing with extended inner ring bearings
- Zone hardened inner ring with 120? spacing setscrew locking with diamond faceted setscrews
- Unique land riding retainer design provides superior pocket clearance that allows for 360? grease circulation around the rolling elements resulting in better retained and utilized lubrication.
- Sealmaster? exclusive lock pin , dimple for direct lubrication and anti-rotation
MSF-39
Sealmaster Mounted Cast Iron Four Bolt Flange Ball Bearing – 52100 Bearing Steel, Black Oxided – Setscrew Lock – MSF-39
$467.41
Out of stock
Out of stock
| Maximum Operating Temperature: | 220 °F | Measure Units: | Inch |
|---|---|---|---|
| Inner-Race Heat-Treat Method: | Zone-Hardened | Duty Series: | Medium Duty |
| Seal Type: | Felt Labyrinth Seal | Insert Material: | 52100 Bearing Steel; Black Oxided |
| Rolling Element: | Ball Bearing | Housing Material: | Cast Iron |
| Expansion: | No | Housing Type: | Flange; Four Bolt |
| Housing Base: | Solid | Insert No.: | 3-27 |
| Retainer Type: | Land Riding Retainer | Bore Shape: | Straight |
| Radial Dynamic Load Capacity (lb): | 13, 971 | Relubricatable: | Yes |
| Pilot Configuration: | No Pilot | Internal Clearance: | Standard |
| Lubrication: | Lithium Complex NLGI 2 Grease | Locking Type: | Setscrew |
| Misalignment: | ±2.0° Misalignment - Static Only | Housing Construction: | One Piece |
| Speed (Max): | 2500 | End Cap: | No |
| Replaceable Insert: | Yes | Housing Color: | Gray |
| Platform: | Gold Line Ball Bearing | Bearing Insert Coating: | Black Oxide Coated |
| Misalignment Type: | Static Only | Outer Ring Land Profile: | Standard |
| T Core: | 5.12987 | Radial Static Load Capacity (lb): | 10, 063 |
| UPC: | 662461014653 | Weight: | 15.42 LB |
| Packaged Length: | 8.13 Inches | Packaged Width: | 7.94 Inches |
| Packaged Height: | 3.5 Inches | HTC: | 8483.20.4040 |
| Country of Origin: | United States of America |
