- Metric stud type cam follower
- Crowned outside diameter
- Needle rolling elements
- Hex hole
- LUBRI-DISC® seal
- Jam nuts and lube fitting included
MCF 52 SB
McGill CAMROL® Crowned Metric Cam Follower – Stud Mount Roller – Hex Hole – Sealed – MCF 52 SB
$199.38
Availability: 11 in stock
Availability: 11 in stock
| Limiting Speed: | 3 | Hex/Slot: | Hex Hole |
|---|---|---|---|
| Sealing: | Sealed | Adjustment: | None |
| Dynamic Track Roller Load Rating (N): | 25, 690 N | O.D. Configuration: | Crowned |
| Series: | Metric CAMROL® | Rolling Element: | Needle Roller - Full Complement |
| Dynamic Radial Rating: | 6 | Material: | Bearing Steel, Black Oxide Finish |
| Stud Type: | Standard Stud | Static Track Roller Load Rating: | 47 |
| Platform: | CAMROL® | Tolerance Class: | P0 Equivalent |
| Industry Standard: | DIN | Static Load Rating: | 47 |
| Roller Shape: | Crowned | Dynamic Load Rating (N): | 30, 790 N |
| Ability to Relubricate: | Yes | Clamping Torque (Nm): | 118 N·m |
| UPC: | 726166023867 | Weight: | 1.17 LB |
| Packaged Length: | 2.3 Inches | Packaged Width: | 2 Inches |
| Packaged Height: | 2.8 Inches | Country of Origin: | China |
