- Lifetime Warranty – If this bushing ever fails Browning will replace it Free of charge.
- Solid Flange, Double Split Barrel – Assures better concentricity to the shaft.
- 3/4″ per Foot Taper on Barrel – Self locking taper provides the highest degree of mechanical locking product to product.
H 1 1/8
Browning Split Taper Bushing – Inch Bore Type – H 1 1/8
$17.49
Availability: 135 in stock
Availability: 135 in stock
| Product Type: | Split Taper Bushing | Total Length (in): | 1.25 in |
|---|---|---|---|
| Keyseat: | 1/4 x 1/8 | Length Through Bore (in): | 1.25 in |
| Compatible Bore Size [Max] (in): | 1.125 in | Bore Size (in): | 1.125 in |
| Outside Diameter (in): | 2.5 in | Cap Screws (Size): | 1/4 x 3/4 |
| Wrench Torque (in-lb): | 95 | Bushing Type: | H |
| Material: | Sintered Steel or Ductile Iron | Model Name: | H-Bushing_1_Master |
| Bore Type: | Inch | Cap Screws (No.): | 2 |
| UPC: | 662289199082 | Weight: | 0.54 LB |
| Packaged Length: | 2.7 Inches | Packaged Width: | 2.7 Inches |
| Packaged Height: | 1.5 Inches | HTC: | 8483.90.8080 |
| Country of Origin: | United States of America |
